blister packing machine
Price: |
1.0~50000.0 USD |
Payment Terms: |
T/T,L/C |
Place of Origin: |
Zhejiang, China (Mainland) |
Product Detail
Model No.:
DPP-250Z
Production Capacity:
20sets/month
Delivery Date:
45days
Type:
Others
Purpose:automatic packing machine:
capacity: 20-50 times/min
Use: Alu-PVC blister packing machine:
Packaging Material:Aluminiu...
Means of Transport:
Ocean,Air
Packing:
Sea worth wooden case
Application:
Others
Brand Name:
Gaoger
Use:pharmaceutical packing:
Suitable:Alu-Alu Blister pa...
Can be widely used as tablet blister packing machines, capsule blister packing machines, and solid products blister packing machine.
Our DPP-250Z blister packing machines can be widely used as tablet blister packing machines, capsule blister packing machines, and solid products blister packing machines like candy blister packing machines, biscuit blister packaging machines, etc.
Features
1. DPP-250Z blister packing machine follows ergonomic design principles and is in accordance to the GMP and CGMP structure standards.
2. If there is an operational problem, the machine will automatically stop and display what the problem is.
3. The main motors of our DPP-250Z blister packing machines are equipped with a variable frequency speed controller.
4. Modular-type work stations make the adjustment of work stations clear and easy.
5. A safety enclosure is provided to protect equipment and operators.
6. Independent moulds can be assembled and disassembled easily and conveniently.
Bottom
Parameters of DPP-250Z Blister Packing Machine
Maximum blanking frequency | Alu/ PVC: 50 time/min AL/AL 30time/min |
Maximum working capacity | Alu/ PVC: 200 blisters/min AL/AL :120 blisters/min |
Stroke | 130mm (according to customer's request) |
Maximum forming area | 245x122mm |
Maximum forming depth | 18mm (upon request) |
Packaging material | PVC: 260x0.25(0.15-0.5)mm |
PTP: 260x0.02mm |
Power supply | Four wire three phrase 380V 50Hz (220V 60Hz) |
Total power | 5.7KW |
Power of main motor | 1.5KW |
Air flow | 0.38m3/min |
Dimension of machine(L*W*H) | 4200x650x1700mm |
Weight | 1500kg |
